| Quantity: | |
|---|---|
CFD-MWD-AS007
CFDPLAS
39269090.90
CFDPLAS brand of PEEK products has been used on very successfully in the analytical instruments industry,like microwave digestion systems,Sample Preparation,Atomic Absoprtion, ICP-MS, ICP-OES,...and so on.
Microwave Digestion Vessel PEEK Shield is made of PEEK+glass fiber reinforced modified material,which can penetrate and absorb microwave,with ultra-high pressure,compressive strength of 6000PSI,temperature resistance of 300 degrees,corrosion resistance and ultra-high strength to ensure the safety of laboratories and analytical instruments.
Material: Glass fiber reinforced PEEK.
Color:natural(beige), black
Process: Extrusion and precision CNC made,precision injection molding.
Features:
Good wave permeability.
High pressure resistance,up to 260 ℃.
Good chemical resistance.
Superior wear resistance and dimensional stability to 260℃ continuous use
Excellent resistance to chemicals, steam and hydrolysis
Very low moisture absorption
Very high thermal stability (V-O UL 94 rating)
Superb flexural and torsional strength
Abrasion resistant
Good dielectric properties
Good resistance to radiation
Self-extinguishing
PEEK protection shield Specifications and dimensions:
Outer Diameter:33mm,35mm,38mm,41mm,60mm,66mm,or customer made.
Inner diameter:26.6mm,28.5mm,30mm,33mm,43mm,56mm,or customer made.
Length:86mm,100mm,136mm,166mm,175mm,185mm,192mm,225mm,or customer made.
The digestion vessel shields is a kind of digestion equipment that can be used for hydrolysis and acidification of the raw slurry, and the main function is to convert organic matter into soluble organic matter by hydrolysis so that the subsequent sludge dehydration process is easy to complete.It also has the advantages of corrosion resistance,high-temperature resistance,and pressure resistance.
PEEK Protection Shields Applications:
CFDPLAS PEEK microwave digestion outer protection vessel shield are used on Milestone,BERGHOF,CEM,Preekem,Anton- Paar,APL,ANALYTIKJENA,Analab,
SINEO Microwave Digestion systems,LabTech,XinTuo,METASH,AUROA,RAYKOL,POLYTECH,
CNSHP,GDANA,Questron,Titan MPS,SCP,...and so on many analysis Industry brands systems,
Related other type of PEEK products:
PEEK adapter plate,PEEK adapter disc,PEEK Spring,PEEK Dental Block disc,PEEK tube,
PEEK pipes,PEEK valve balls,PEEK Column and Other Parts Used in HPLC instrument,
PEEK samplers,PEEK Valve Seat Used in Coal Mining Shield Support Valve,PEEK screws,
PEEK Nuts,PEEK gaskets,PEEK Ring,PEEK screw cap,
